| Chipset |
Intel G41 / ICH7 |
| CPU SUPPORT |
Intel® Core™2 Quad Processor
Intel® Core™2 Duo Processor
Intel® Pentium® Dual-Core Processor
Intel® Celeron® Dual-Core Processor
Intel® Celeron® Processor 400 Sequence
Maximum CPU TDP (Thermal Design Power) : 95Watt |
| FSB |
Support FSB 800/1066/1333MHz |
| MEMORY |
Support Dual Channel DDR3 800/1066/1333(OC) MHz
2 x DDR3 DIMM Memory Slot
Max. Supports up to 8GB Memory
Note: FSB800 CPU only support DDR3-800 |
| INTEGRATED VIDEO |
Intel Graphics Media Accelerator X4500.
Support RGB with max. resolution 2048 x 1536@75Hz
Max. shared memory 1759MB(DVMT) *
Supports DX10
* The Max shared memory size will be available only when 4GB memory or more installed on Motherboard under the 64-bit OS. |
| STORAGE |
4 x SATA II Connector
1 x IDE Connector |
| LAN |
Realtek RTL8103EL - 10/100 Controller |
| CODEC |
Realtek ALC662 6-Channel HD Audio |
| USB |
4 x USB 2.0 Port
2 x USB 2.0 Header |
| EXPANSION SLOT |
1 x PCI-E x16 Slot
2 x PCI Slot |
| REAR I/O |
1 x PS/2 Mouse
1 x PS/2 Keyboard
4 x USB 2.0 Port
1 x VGA Port
1 x LAN Port
3 x Audio Jacks |
| INTERNAL I/O |
2 x USB 2.0 Header
4 x SATA II 3Gb/s Connector
1 x IDE Connector
1 x Floppy Connector
1 x Front Audio Header
1 x Front Panel Header
1 x CPU Fan Connector
1 x System Fan Connector
1 x COM Port Header
1 x Printer Port Header |
| DIMENSION |
Micro ATX Form Factor Dimension: 23.5cm x 18.2cm ( W x L ) |
| OS SUPPORT |
Support Windows 2000 / XP / Vista / 7 / 8 |
| ACCESSORIES |
2 x SATA Cable
1 x I/O Shield
1 x Fully Setup Driver CD
1 x Quick Guide |
| FEATURES |
Windows 8 Ready
Supports Solid capacitor
Supports BIOS-Flasher |
